The right hand side is dimensionless, it's the constant π = 3.14... which is defined by the relation of two lengths, the circumference and the diameter of a circle. The left hand side requires to plug in the dimensions of the named physical quantities:

• Planck energy: given in Joules [J]
• Pressure at the core of the Earth: given in Pascals [Pa]
• Prius combined EPA gas mileage: miles per gallon, given in meters per cubic meter [m/m³]
  • Fuel efficiency has two formats that are commonly used: length per volume and volume per length. The former must be used here in order to get the units to cancel correctly.
• Minimum width of the English Channel: given in meters [m]

When plugged into the left hand side this amounts to:

Using the following unit relations (this does not reduce units to the seven SI base units, but does use some derived units for cancelation):

• 1 Pascal [Pa] = 1 Joule per cubic meter [J/m³]

Note that for dimensional analysis constant factors are not taken into account. Here square brackets are used to denote dimensional analysis. In the above equation the unit of energy (joule) as well as all the unit of volume (cubic meter) cancel out each other.

Another aspect of the comic is, that sometimes dimension analysis of equations that were not derived but rather "made up" can provide insight. However, in reality such an equations would have to be somehow "motivated", which is more of an art than science and requires great experience in the field the equation should relate to. The presented equation combines values that have no immediate causal relation with each other, so it does not make sense. Furthermore, since the values have absolutely no causal relation to each other, the ratios presented are simple coincidence; despite Cueball's claim, building a better Prius would not cause any changes to the English Channel.^{[citation needed]}

The title text also refers to this, as a higher pressure at Earth's core could also balance the equation, keeping the result constant equal to π. The Planck energy is an absolute, however, so it is not mentioned as a way to balance the next version of Prius.

The Planck energy is the only nearly exact value we do have. Compared to other Planck values it is very large (macroscopic).

E_planck = 1.956 x 109 J

Pressure at the core of the Earth ranges from 330 to 360 gigapascals. Using a simple value like this:

P_core = 350 GPa = 3.5 x 1011 J/m³

Prius combined EPA gas mileage: For the third generation (from 2010) the City mileage is 51 mpg and the Highway mileage is 48 mpg. But it is the combined EPA gas mileage which is used in the equation and that is 50 miles per gallon.

50 mpg => 21,000,000 m/m³

Minimum width of the English Channel is about

33.1 km = 33,100 m

Calculating from these values you will get π = 3.54... that is pretty close to π = 3.14... while using a Planck value. According to Cueball this will be within the experimental error (the combined error for all four numbers - none are exact numbers). For instance if you tried the ePrius you would probably get closer to that target — as the mileage in real life usually is somewhat lower than the value given — and that would reduce the result.

Wolfram|Alpha can find most of the statistics and do the calculations.
